HPE ProLiant DL345 Gen10 Plus Entry
Stock: n/a
Réf. fabricant:
Copié dans le presse-papier
Cliquez pour copier
Réf. SHI:
Copié dans le presse-papier
Cliquez pour copier
|
Détails rapides
|
|---|
|
HPE ProLiant DL345 Gen10 Plus Entry
- Server
- rack-mountable 2U
- 1-way
- 1 x EPYC 7232P / up to 3.2 GHz
- RAM 32 GB
- SAS
- hot-swap 3.5" bay(s)
- no HDD
- Gigabit Ethernet
- monitor: none
| Détails supplémentaires | |
|---|---|
| Réf. fabricant: | P39265-B21 |
| Réf. SHI: | 42506758 |
| Catégorie: | Servers |
| UNSPSC: | 43211501 |
| Fabricant: | Hewlett Packard Enterprise |
| Type de produit: | Hardware |
| Informations générales | |
|---|---|
| Category | Servers |
| Description | HPE ProLiant DL345 Gen10 Plus Entry - Server - rack-mountable 2U - 1-way - 1 x EPYC 7232P / up to 3.2 GHz - RAM 32 GB - SAS - hot-swap 3.5" bay(s) - no HDD - Gigabit Ethernet - monitor: none |
| Manufacturer | Hewlett Packard Enterprise |
| UNSPSC | 43211501 |
| Descriptif principal | |
| Chassis / Form Factor | Rack-mountable |
| Chassis / Server Storage Bays | Hot-swap |
| Chassis / Server Swappable Drive Interface | SAS |
| Dimensions & Weight / Depth | 74.9 cm |
| Dimensions & Weight / Height | 8.75 cm |
| Dimensions & Weight / Width | 44.54 cm |
| Display / Type | None. |
| Header / Brand | HPE |
| Header / Country Kits | Worldwide |
| Miscellaneous / Product Color |
|
| Networking / Data Link Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3.1 GHz |
| Processor / Manufacturer | AMD |
| Processor / Number of Cores | 8-core |
| Processor / Processor Number | 7232P |
| Processor / Type | EPYC |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Memory Speed | 3200 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 0 GB |
| System / Type | Server |
| Cache Memory | |
| Cache Per Processor | 32 MB |
| Installed Size | 32 MB |
| Dimensions & Weight | |
| Depth | 74.9 cm |
| Height | 8.75 cm |
| Width | 44.54 cm |
| Environmental Parameters | |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays | 8 (total) / 8 (free) x hot-swap 3.5" LFF |
| Interfaces |
|
| Slots | 3 (total) / 3 (free) x PCIe 4.0 x16 - full-length, full-height (x16 mode) |
| General | |
| Hot-Swap Bays Qty | 8 |
| Localization | Region: Worldwide |
| Product Form Factor | Rack-mountable - 2U |
| Server Scalability | 1-way |
| Type | Server |
| Graphics Controller | |
| Video Interfaces | VGA |
| Video Memory | 16 MB |
| Hard Drive | |
| Type | No HDD |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site - response time: next business day |
| Miscellaneous | |
| Compliant Standards | AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, Redfish API, UEFI, SMBIOS 3.1 |
| Included Accessories | LFF Easy Install rails, 6 x standard fans |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Compliant Standards | OCP 3.0 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Features | Wake on LAN (WoL), PXE support |
| Operating System / Software | |
| Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Provided | 500 watt |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Processor / Chipset | |
| Clock Speed | 3.1 GHz |
| CPU | AMD EPYC 7232P |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Max Turbo Speed | 3.2 GHz |
| Number of Cores | 8-core |
| RAM | |
| Configuration Features | 1 x 32 GB |
| Effective Memory Speed | 3200 MHz |
| Features | Registered, 8-channel memory architecture, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only |
| Form Factor | DIMM 288-pin |
| Installed Size | 32 GB (installed) / 2 TB (max) |
| Rated Memory Speed | 3200 MHz |
| Slots | 16 (total) / 15 (empty) |
| Technology | DDR4 SDRAM |
| Storage Controller | |
| Buffer Size | 2 GB |
| Channel Qty | 8 |
| Controller Interface Type | SAS 12Gb/s |
| Storage Controller Name | HPE Smart Array P408i-a SR Gen10 |
| Type | 1 x RAID |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 3.0 |
| EPEAT Compliant | EPEAT Bronze |
